Solar Air Conditioner
WH-26GW/DCBrand:
WanheMax.Power:
1HPCompressor :
DC 24/48VCooling:
9000 Btu/hFeatures
Specifications
DC AIR CONDITIONER Series |
|||||
| Model No | WH-26GW/DC | WH-35GW/DC | WH-50GW/DC | ||
| 1HP | 1.5HP | 2HP | |||
| 0.75ton | 1ton | 1.5ton | |||
| Performance | |||||
| Capacity | Cooling | Btu/h | 9000 | 12000 | 18000 |
| W | 2600 | 3500 | 5200 | ||
| Heating | Btu/h | 10000 | 13000 | 20000 | |
| W | 2800 | 3700 | 6000 | ||
| Noise | Indoor | dB(A) | ≤40 | ≤42 | ≤43 |
| Outdoor | dB(A) | ≤50 | ≤52 | ≤54 | |
| Air Circulation | m³/h | 450 | 550 | 650 | |
| Suitable Area | m² | 10~15 | 12~25 | 20~30 | |
| EER | W/W | 4.56 | 4.67 | 4.73 | |
| Btu/h/w | 15.79 | 16.00 | 16.36 | ||
| Refrigerant | R-134A | R-134A | R-134A | ||
| Compressor | DC 24/48V | DC 48V | DC 48V | ||
| Work Temp. | ℃ | -15~60 | -15~60 | -15~60 | |
| Power Consumption | |||||
| Power Input | W | 500 | 750 | 1100 | |
| Rated Current | A | 19 | 16 | 22 | |
| Input Power | V | DC 24/48 | DC 48 | DC 48 | |
| Dimension | |||||
| Indoor Unit | Product Size | mm | 745*255*195 | 775*260*210 | 1070*385*265 |
| Packing Size | mm | 780*240*305 | 840*325*265 | 1100*400*285 | |
| Outdoor Unit | Product Size | mm | 790*260*540 | 790*260*540 | 850*290*580 |
| Packing Size | mm | 910*370*610 | 910*370*610 | 995*390*650 | |
| Weight | |||||
| Indoor Unit | N.W./G.W. | kg | 11/13 | 13/15 | 15/17 |
| Outdoor Unit | N.W./G.W. | kg | 38/40 | 45/48 | 48/52 |
