WHSL-182M80
WHSL-182M100
WHSL-182M120
WHSL-182M160
|
|
120w Mono Solar Panel
WHSL-182M120Brand:
wanheMax.Power:
120WDimensions:
800 X 760 X 25 mmCertificate:
CE SUNCAPWarranty:
12 YEARPayment:
T/T, L/C,etc;
120w Mono Solar Panel,Solar Panel,Solar Panel Supplier,Mono Solar Panel
WH Company Supply High Quality Solar Panel,Mono Solar Panel,The Solar Cell Effciency Can Be Reached 18%-21%.
Technical Parameter of Mono Solar Panel
|
Module |
WHSL-182M120 |
|
Power (W) |
120 |
|
Voltage at Pmax (V) |
18.2 |
|
Current at Pmax (A) |
6.59 |
|
Open Circuit Voltage (V) |
22.3 |
|
Short Circuit Current (A) |
7.11 |
|
Dimension （mm） |
800*760*30 |
|
Module weight (Kg) |
6.1 |
|
Terminal Box |
IP65 |
|
Maximum system voltage (V) |
DC1000 |
|
Operating Temperature(℃) |
-40℃ ---85℃ |
