WH-CM20D-20
WH-12200
WH-12100
WH-SG1220W
![]() |
![]() |
DC solar lighting system
WH-SG1220WBrand:
WANHEMax.Power:
20WDimensions:
OTHERCertificate:
CE ,UL,INMETRO, SUNCAPWarranty:
1 YEARPayment:
T/T, L/C,etc;
• System Features
• Solar independent power supply
• High photoelectric conversion efficiency
• Good compatibility, stability performance
• Simple installation, plug and play
• Smart and parctical, can be customzied
• Built-in maintence-free battery, safe and reliable
Model : | WH-SG1220W | |||||||
Solar panel | 18V-20W with 8M cable | |||||||
Battery | 12V 12AH lead-acid | |||||||
LED bulb | 12V-3W*2pcs &12V/5W*2pcswith 4M cable and switch | |||||||
USB output | 5V-1A*2 | |||||||
Solar controller | 12V-5A | |||||||
Min stereo | MP 3 player, Radio function | |||||||
Output voltage | USB 5V output: 5V-2A(MAX) | |||||||
DC 12V output: 12V-0.5A*6(MAX) | ||||||||
Charging mode | PWM | |||||||
Charging time | 10H | |||||||
Fuse | 15A | |||||||
Package |
2pcs/CTN, 13.25KG, 535*350*315mm Solar panel package: 10pcs/CTN, 23.15KG, 510*340*385mm |
|||||||
Color | Yellow |
