DC solar lighting system

WH-SG1250W

Brand:

WANHE

Max.Power:

50W

Dimensions:

OTHER

Certificate:

CE ,UL,INMETRO, SUNCAP

Warranty:

1 YEAR

Payment:

T/T, L/C,etc;
Features
Specifications

Model : WH-SG1250W
Solar panel 18V-50W with 8M cable
Battery 12V 17AH lead-acid
LED bulb 12V-3W*3pcs &12V/5W*3pcswith 4M cable and switch
USB output 5V-1A*2
Solar controller 12V-5A
Min stereo MP 3 player, Radio function
Output voltage USB 5V output: 5V-2A(MAX)
DC 12V output: 12V-0.5A*6(MAX)
Charging mode PWM
Charging time 10H
Fuse 15A
Package 2pcs/CTN, 17KG, 535*350*315mm
Solar panel package: 5pcs/CTN, 23KG, 725*530*240mm
Color Yellow
